The encoder’s standout feature is its IP69K protection class, which complies with ISO 20653 standards to withstand 80°C high-temperature, 100bar high-pressure washdown—critical for food processing plants where daily cleaning is required to meet hygiene regulations. Its 304 stainless steel housing offers excellent resistance to food-grade cleaners, corrosive chemicals, and outdoor salt spray, ensuring durability in both indoor washdown and outdoor field use. The battery-free multi-turn design uses a precision mechanical gear train to store rotation data, eliminating the risk of contamination from battery leakage and reducing maintenance requirements. Dual CANopen and RS232 output interfaces enable flexible integration with PLC and SCADA systems, supporting remote monitoring and control of washdown equipment. With ±0.06° accuracy and ≤2μs response time, it delivers real-time position data to control conveyor speeds, mixer angles, and outdoor gate positions. The wide operating temperature range of -25°C to +85°C ensures consistent performance in outdoor winter and summer conditions.
This IP69K waterproof encoder features an 80mm diameter 304 stainless steel housing, weighing 650g for stable mounting in washdown environments. The 8mm solid shaft is precision-machined to minimize radial play, ensuring smooth rotation and accurate signal output. It supports a maximum rotational speed of 8,000 RPM, with 22-bit resolution (1024 multi-turn counts + 4096 single-turn counts) for precise position tracking. The operating temperature range of -25°C to +85°C ensures consistent performance in extreme cold and heat, while the supply voltage range of 9-36V DC accommodates diverse industrial power systems. Compliance with CE, RoHS, and ISO 20653 standards guarantees adherence to global safety and hygiene regulations. The encoder uses a contactless magnetic sensing technology, eliminating mechanical wear and extending service life to over 5 million rotations. Sealed stainless steel connectors are provided to prevent water ingress during washdown, ensuring reliable signal transmission in wet environments.
This IP69K waterproof encoder is widely used in food processing plants, where it provides position feedback for conveyor belts, mixing tanks, and filling equipment, ensuring precise control of production lines and compliance with food hygiene regulations. In slaughterhouses, it controls the position of meat processing equipment, such as cutting blades and bone separators, improving production efficiency and food safety. In outdoor utility applications, it monitors the position of water gates and dam controls, enabling precise water flow management in rivers and reservoirs. In agricultural machinery, it tracks the position of seed drill depth and fertilizer spreader controls, improving crop yield and reducing waste. It also suits car wash facilities, where it controls the position of rotating wash arms, ensuring thorough vehicle cleaning without damaging equipment. Additionally, it is deployed in marine environments, such as boat lifts and dock cranes, providing reliable position feedback in saltwater conditions with high-pressure washdown requirements.
