It adopts X-ray fluorescence spectrum online detection technology, which can be integrated into the existing production pipeline to achieve a batch detection speed of 100 pieces per minute, and complete the detection of each sample to be tested without manual operation. It is equipped with a high-sensitivity array detector, with a detection accuracy of ±0.03%, and can detect the content of common precious metals such as gold, silver, platinum and palladium in real time. The device supports docking with PLC control system, and can automatically remove samples that do not meet the purity standards, realizing full-process automated detection. It has a built-in automatic calibration system, which can automatically correct the impact of vibration and temperature changes during pipeline operation on the detection results. It adopts a stainless steel one-piece shell with good dust and rust resistance, adapting to the complex environment of the production workshop, and supports remote monitoring and data statistical analysis.
The overall size is 1200mm (length) × 800mm (width) × 1500mm (height), and the total weight is about 85kg. It is powered by 380V AC three-phase mains power, adapting to the power supply standards of industrial production workshops. The detection speed can reach 100 pieces per minute, and it can adapt to pipelines of different widths (supporting 100mm-500mm width adjustment). It is equipped with a high-sensitivity silicon drift array detector, and the detection elements cover common precious metals such as gold, silver, platinum and palladium, with a detection accuracy of ±0.03%. It supports docking with PLC control system, and can automatically realize the sorting and removal of unqualified samples. It is equipped with an Ethernet data transmission interface, which can synchronize detection data to the factory management system, supporting batch data storage and export. The fuselage is made of 304 stainless steel one-piece shell, with IP65 dust and water protection rating, adapting to the complex operation environment of the production workshop. It has passed international authoritative certifications such as CE and ISO9001, meeting industrial production equipment standards.
It is suitable for batch incoming material detection in precious metal recycling pipelines, raw material quality inspection in jewelry production pipelines, precious metal content screening in electronic waste recycling, thickness detection of industrial precious metal coatings and other scenarios. It can realize fully automated online detection, and complete the detection and sorting of a large number of samples without manual intervention, improving production efficiency and detection accuracy, and providing reliable quality guarantee for large-scale production and recycling.
