Chemical anchoring system features: 1) Vinyl ester resin resists damp heat aging, compressive strength ≥80MPa; 2) Good fluidity ensures ≥95% hole fill; 3) Adjustable cure time: Fast-set (10 min), Standard (30 min); 4) Suitable for cracked concrete (crack width ≤0.3mm); 5) Tensile capacity 15-30kN (for M12); 6) Chemical corrosion resistant, pH range 2-12; 7) Glass capsule packaging ensures uniform mixing; 8) Installation temperature range -5°C to +40°C; 9) Fire rating up to R90 (90 minutes); 10) Seismic performance meets IBC standards.
Kit includes: 1) Fully threaded stud, Grade 5.8; 2) Chemical adhesive capsule, volume calculated for hole size; 3) Installation tools. Technical parameters: 1) Continuous thread on stud allows embedment depth adjustment; 2) Capsule diameter matches standard drill bits; 3) Minimum edge distance ≥5×embedment depth; 4) Minimum spacing ≥2×embedment depth; 5) Standard embedment depth 10-12d (d=stud diameter); 6) Substrate strength ≥C20 concrete; 7) Packaging includes instructions and certificate; 8) Shelf life 18 months (cool, dry environment).
Post-installation engineering uses: 1) Structural strengthening: Anchorages for beam/column enlargement; 2) Curtain wall installation: Back-mounted fixtures for stone/glass façades; 3) Equipment mounting: HVAC, pipe support fixing; 4) Bridge reinforcement: Parapet, signboard installation; 5) Industrial flooring: Floor rail, equipment base anchoring; 6) Seismic retrofit: Seismic brace, damper connections; 7) Roof equipment: Solar mount, ventilator fixing; 8) Interior fit-out: Heavy-duty cabinet, partition stud fixing.
