The solution’s core competitive edge is its audio rendering technology, which can place and move audio objects in 3D space with pinpoint accuracy, creating a truly immersive audio experience that makes audiences feel as if they are inside the movie or performance. It integrates an AI spatial audio calibration system that automatically analyzes the venue’s acoustic properties, including room size, wall materials, and seating arrangement, and adjusts audio parameters in real time to ensure consistent sound quality across all seating zones. The 1000W high-power subwoofer delivers deep, resonant bass down to 20Hz, enhancing the impact of action scenes and musical performances. The system supports seamless integration with professional video projectors and audio mixing consoles, as well as cloud-based content streaming, allowing venue managers to access a vast library of high-definition audio and video content. Additionally, it features a redundant signal transmission system to ensure uninterrupted operation during critical performances.
The system adopts a 7.2.4 Dolby Atmos channel configuration, including 7 main speakers, 2 subwoofers, and 4 overhead speakers. Each main speaker has a power output of 200W, with a frequency response range of 40Hz-20kHz and a maximum sound pressure level of 120dB. The two 1000W subwoofers have a frequency response range of 20Hz-200Hz, delivering deep, powerful bass. The overhead speakers have a power output of 150W and a frequency response range of 80Hz-20kHz, providing immersive overhead audio effects. The main control unit supports HDMI 2.1, optical, RCA, and Dante interfaces, allowing for seamless connection to 4K projectors, Blu-ray players, and professional audio mixing consoles. The AI spatial audio calibration system can analyze the venue’s acoustic properties within 10 minutes and adjust audio parameters such as equalization, delay, and volume to ensure optimal sound quality. The main control unit measures 500mm (W) × 350mm (D) × 120mm (H) and weighs 20kg, with a power consumption of 1500W and support for AC 100-240V universal voltage.
This solution is ideal for cultural centers, performing arts venues, university auditoriums, high-end commercial cinemas, and luxury private multi-function halls. Typical application scenarios include: screening Hollywood blockbusters with Dolby Atmos surround sound, providing audiences with a cinema-grade immersive audio experience; hosting live concerts and theatrical performances, where the object-based audio rendering technology can accurately reproduce the sound of musical instruments and vocal performances; staging immersive art exhibitions, where the 3D audio system can enhance the audience’s sensory experience; and hosting high-end corporate events or product launches, where the system can play high-definition promotional videos with immersive audio. It is also suitable for use in university auditoriums that host film screenings, guest lectures, and student performances, as its versatile configuration can meet the diverse audio needs of different events.
