It adopts a multi-group scissor arm linkage structure to ensure lifting stability under large platform and heavy load, avoiding platform deformation. It is equipped with a light curtain safety protection device, which will automatically stop lifting when detecting personnel or obstacles in the operation area to avoid safety accidents. It is equipped with an overload weighing system, which triggers sound and light alarms and stops operation when the load exceeds the rated value. The high-pressure hydraulic system improves lifting speed and shortens operation cycle. It supports remote PLC monitoring, which can view real-time equipment operation status and maintenance alarms, reducing operation and maintenance costs.
Rated load capacity: 5000kg, maximum lifting height: 10m, working platform size: 3000mm ×2000mm ×100mm, power configuration: 380V 50Hz 3-phase AC, hydraulic system working pressure: 20MPa, overall dimensions for installation base: 3200mm (width) ×4200mm (length) ×4500mm (height), total self-weight: 8500kg, protection grade: IP65, control system: PLC remote monitoring + local touch control, safety devices: light curtain safety protection, overload weighing alarm, anti-falling safety device, emergency stop button.
It is suitable for heavy-duty pallet cargo transfer in large warehousing centers, cross-floor parts handling in automobile manufacturing workshops, large equipment accessory transportation in heavy industry enterprises, and large cargo vertical loading and unloading in logistics parks. It can adapt to handling of containers, heavy pallets and large equipment, and is suitable for all-weather outdoor operation scenarios.
