The biggest feature of this mini swing is its portable, modular design. The entire device is divided into 5 detachable modules, each weighing less than 150 lbs, which can be transported by ordinary pickup trucks and installed by 2-3 people within 8 hours. The manual assist mechanical gear system reduces the force required to pull the swing by 60%, allowing staff to easily pull the swing to the required amplitude without additional power. It is equipped with a reinforced safety rope and quick-release harness, meeting strict EN 1176-3 safety standards, ensuring user safety during manual operation. The aluminum alloy frame is treated with anodization, providing excellent anti-corrosion performance, while the carbon fiber seat reduces the overall weight without compromising strength. Additionally, it can be fixed using expansion bolts instead of concrete foundations in suitable cliff locations, further reducing installation time and costs, solving the problem of high infrastructure investment for small attractions.
The main frame is made of 6061-T6 high-strength aluminum alloy, with a total height of 12ft and a horizontal projection length of 18ft from the cliff edge. The seat is made of carbon fiber composite material, weighing only 12 lbs, with a seat width of 32 inches and a backrest height of 34 inches. The safety rope uses 45mm-wide high-strength polyester webbing, with a breaking strength of 4,800 lbs, and is equipped with a self-locking hook to prevent accidental loosening. The mechanical gear system has a gear ratio of 3:1, reducing the pulling force required from 200 lbs to 70 lbs. The entire device weighs 750 lbs, and each module can be packed in a standard wooden box for transportation. The installation requires 8 expansion bolts with a diameter of 20mm and a length of 600mm, suitable for cliff surfaces made of concrete, rock, or solid masonry. The safety harness uses a three-point design, which is easy to wear and adjust, suitable for users of different body types.
This mini portable cliff swing is ideal for small mountain scenic spots, rural tourism villages, outdoor adventure camps, and temporary event sites. In small mountain scenic spots with limited budget, it can be installed in a suitable cliff location to add a characteristic amusement facility without large-scale infrastructure investment. In rural tourism villages, it can be combined with farm stays, fruit picking, and rural experience projects to attract urban tourists seeking simple adventure experiences. In outdoor adventure camps, it can be used as a temporary attraction for campers, providing a fun high-altitude activity during camping trips. It is also suitable for temporary events such as outdoor adventure festivals and mountain sports competitions, as it can be quickly installed and disassembled according to the event schedule. For remote areas without electricity, it is an ideal choice due to its manual operation mode, bringing high-altitude amusement experiences to areas with limited energy supply. Additionally, it can be used in outdoor education bases, providing a low-risk adventure project for students to exercise their courage and hands-on ability.
