The core advantage of this swing is its intelligent PLC control system, which can automatically adjust swing parameters according to user weight and preference, providing a personalized experience while ensuring operational safety. The real-time remote monitoring system transmits data such as swing angle, load capacity, and frame temperature to the scenic spot's smart management platform in real time, with automatic alarm functions for abnormal data. It is equipped with a backup power supply system, which can switch to a generator within 3 seconds in case of power outages, ensuring that users are safely lowered to the ground. The anti-corrosion coating on the frame uses environmentally friendly epoxy resin material, which can resist salt spray corrosion and acid rain erosion, extending the device's service life by 30% compared to traditional frames. Additionally, the one-button operation system simplifies the workflow for staff, reducing training costs and operational errors, solving the problem of high labor costs and low efficiency in traditional amusement facility operation.
The main frame is made of 10mm-thick Q355B alloy steel, with a total height of 20ft and a horizontal projection length of 28ft from the cliff edge. The seat is made of high-density memory foam wrapped in wear-resistant PU leather, with a seat width of 36 inches and a backrest height of 38 inches. The safety harness uses 50mm-wide high-strength nylon webbing, with a breaking strength of 5,500 lbs, and is equipped with an electronic lock that can only be opened after the swing stops completely. The PLC control system has a response time of less than 0.05 seconds, with swing speed adjustable from 0 to 13 ft/s and swing angle adjustable from 0 to 70 degrees. The real-time monitoring system includes 10 sensors, and the backup generator has a power of 5 kW, which can support the device to operate continuously for 4 hours. The entire device weighs 3,000 lbs and requires a concrete foundation of 3.5m×3.5m×0.9m for installation. The control system also supports data export, helping scenic spots analyze user behavior and optimize operation strategies.
This smart electric-controlled cliff swing is suitable for smart tourism scenic spots, cultural tourism complexes, high-altitude viewing platforms, and eco-tourism areas. In smart tourism scenic spots, it can be connected to the scenic spot's overall management system, realizing unified scheduling and data analysis, improving the level of intelligent operation. In cultural tourism complexes, it can be combined with virtual reality (VR) devices to create a VR+high-altitude swing experience, enhancing the immersive feeling for users. For eco-tourism areas with strict environmental protection requirements, its energy-efficient electric system and environmentally friendly coating meet ecological protection standards, avoiding negative impacts on the natural environment. It is also suitable for scenic spots in areas with unstable power supply, as the backup generator ensures uninterrupted operation. In addition, it can be used in corporate team-building bases, providing a safe and controlled high-altitude challenge project to enhance team courage and cooperation awareness.
